Quantity:
Item: PA15-SIT - 16.3mm flat FDA Silicone suction cup
| |
Item#: PA15-SIT
Price: £2.86 ea.
|
16.3mm flat FDA Silicone suction cup
General Specifications
Style: Flat
Cleats: No
Material: Silicone
Thread Size: None
Outside Diameter: 15.0mm
Weight(lbs): 0.0022
Color: Translucent
Lifting Capacity: See Chart [X] CloseLifting Capacity for Item PA15-SIT
| Level of Vacuum (inHg) |
Horizontal |
Vertical |
| 6"Hg |
0.32 lbs. |
0.16 lbs. |
| 18"Hg |
0.98 lbs. |
0.49 lbs. |
| 27"Hg |
1.47 lbs. |
0.73 lbs. |
***Disclaimer: Lifting capacity for handling a non-porous surface. Figures are theoretical and based on 80% of suction cup outside diameter with a 2:1 safety margin for horizontal lifting and a 4:1 safety margin for vertical lifting.
Includes fitting?: NO
 Recommended replacement for: PFG-15A-SI, VPG15SI, PFG 15 SI-55 N005, 10.01.01.00031 , C-F15-SIT, 102.015.030.2, 10.015.139.02, C-PFG15-SIT |
|
|
|
Material Specifications
| Material name |
Wear Resistance |
Oil |
Weather & Ozone |
Temperature Range |
| Silicone |
Good |
Good |
Excellent |
-94 to 392 °F (-70 to 200 °C) |
Video of Product in Action
No Videos Available for: PA15-SIT
Dimensional drawing for Item: PA15-SIT
Click on the image to enlarge
Parts and accessories for Suction Cup: PA15-SIT
Fitting Image for 400.005 |
General Specifications
Material: Aluminum
Weight: .0005(lbs)
Dimensions: M5 male
Price: £1.84 each
Description: M5 flange fitting
Add to Cart
|
Dimensional Fitting Drawing for 400.005 |
|
|---|
Fitting Image for 130.005 |
General Specifications
Material: Aluminum
Weight: .0015(lbs)
Dimensions: M5 female
Price: £3.04 each
Description: M5 female fitting for PFG, PJG 5-15mm cups
Add to Cart
|
Dimensional Fitting Drawing for 130.005 |
|
|---|
