Item: MSVG-360M - Multi-stage vacuum generator. 12.7 SCFM. 22 Hg ... (Full Description below)
|
Item#: MSVG-360M Price: £218.75 ea.
|
Multi-stage vacuum generator. 12.7 SCFM. 22 Hg (includes 4x M6 top, flush mount screws)
General Specifications
Vacuum Flow(SCFM): 13.8 Vacuum Port: G1/2" Supply Port: 8mm tube Air Consumption: 4.59 Max Vac -inHg": 22 Weight(lbs)": .4955
|
|
|
|
Additional Information
No additional information available for this item
CAD files for this Product
N/A
Supply Press (PSI) |
Max Vacuum "Hg |
0"Hg |
3"Hg |
6"Hg |
9"Hg |
12"Hg |
15"Hg |
18"Hg |
21"Hg |
24"Hg |
27"Hg |
87 |
22 |
13.77 |
7.42 |
4.77 |
3.53 |
2.30 |
1.24 |
1.07 |
0.65 |
0.00 |
0.00 |
Supply Press (PSI) |
Max Vacuum "Hg |
3"Hg |
6"Hg |
9"Hg |
12"Hg |
15"Hg |
18"Hg |
21"Hg |
24"Hg |
27"Hg |
|
26.5 |
0.85 |
1.42 |
2.83 |
5.09 |
10.19 |
15.85 |
24.62 |
0.00 |
|
Supply Press (Bar) |
Air Cons L/min |
Max Vacuum "Hg |
0 Kpa |
10 Kpa |
20 Kpa |
30 Kpa |
40 Kpa |
50 Kpa |
60 Kpa |
70 Kpa |
80 Kpa |
90 Kpa |
6 |
|
22 |
390 |
210 |
135 |
100 |
65 |
35.1 |
30.3 |
18.3 |
|
|
Supply Press (Bar) |
Max Vacuum "Hg |
10 Kpa |
20 Kpa |
30 Kpa |
40 Kpa |
50 Kpa |
60 Kpa |
70 Kpa |
80 Kpa |
90 Kpa |
3.14 |
26.5 |
0.05 |
0.1 |
0.18 |
0.36 |
0.56 |
0.87 |
|
0.03 |
|
Dimensional drawing for Item: MSVG-360M
Click on the image to enlarge
Parts and accessories for Item: MSVG-360M
|
Description: MSVG mounting bracket M12 bolt type
General Specifications
Type: Brackets for Generators
Material: Steel
Price: £10.50 each
Add to Cart
|
Dimensional Fitting Drawing for GMB-H-M12 |
|
---|
|
Description: MSVG mounting bracket M6 bolt with L-bracket
General Specifications
Type: Brackets for Generators
Material: Steel
Price: £10.15 each
Add to Cart
|
Dimensional Fitting Drawing for GMB-G-M6 |
|
---|
|
Description: MSVG mounting bracket M12 bolt with L-bracket
General Specifications
Type: Brackets for Generators
Material: Steel
Price: £18.90 each
Add to Cart
|
Dimensional Fitting Drawing for GMB-K-M12 |
|
---|
